※Structural feature
PRODUCT SPECIFICATIONS
What you want to know is that we work hard.
1. temperature requirement：160—200℃ steam pressure：0.8-1.3Mpa 2. air source pressure：0.6—0.9Mpa 3. Cooling stereotypes length：4m Heating plate quantity：12 pieces 4. hydraulic system pressure：6---8MpaParameters
※Technical parameters
※Roller diameter parameters
1. upper drive rubber roller diameter：￠475mm lower drive rubber roller diameter：￠350mm Wear rubber Outsourcing 2. Former follower with roller diameter：￠176mm back setting belt driven roller diameter：￠176mm 3. Platen roller：￠85mm Setting roller diameter：￠86mm 4. upper belt tension roller diameter：￠155mm upper roll diameter with detuning：￠124mm 5. Lower belt tension roller diameter：￠130mm Entrusted with the roll diameter lower belt：￠130mm Note: All the roller surface after grinding are hard chrome plated。★Hot plate with intensive gravitational roll structure. Roll adopt pneumatic lifting. ★Heating plate heat transfer pipe temperature control sub-four-segment, with a temperature display. ★on cotton use two-cylinder S type cotton belt with the tensioning device. ★lower belt adopt pneumatic tensioning. ★Drive roller coated with attached wear-resistant rubber ，showed a herringbone structure，With a high, ensure smooth cardboard output。 ★Main drive motor for frequency conversion motor，low-speed torque，wide speed range ,reliable, and easy maintenance. ★hot plate internal for partition isolation structure,s-shaped flow of steam，Steam, water separation function significantly improves the utilization of steam。※Powered motor parameters
1、Main drive motor power：22KW 380V 50Hz Continuous (S1) working standard※Mainly purchased parts, raw materials and origin
